KV40 Metal Cutting Vertical Bandsaw

Metal Bandsaw

KV40 Metal Cutting Vertical Bandsaw

A large capacity bandsaw with a powerful 1.5kW motor, this sturdy machine is capable of heavy cuts for prolonged periods. Two speeds, three types of available blade and 410mm throat capacity makes the KV40 a versatile resource for preparing a wide variety of stock - including thicker sheet material. The table inclines for cutting mitred edges and the machine is supplied with a mitre-fence for cross-cutting angles and mitred corners. Strips and repeat widths are quickly obtained by working off the adjustable fence. A useful feature is the built-in shear, welding, grinding and annealing facility for making-up or repairing blades in-house.

N.B. Work supports (see SF-ROLLERSTAND5 in prices below) must be used for long pieces to stop tipping.
Table Size:600(W) x 500(D)mm
Table Tilt:0° - 15°
Throat Width:410mm
Clearance Height:310mm
Max. Blade Width:16mm
Motor:1.5kW (2hp)
Dimensions:1110(W) x 590(D) x 1950(H)mm
Power Requirements:415V 4.0kW, Lockable rotary isolator
Warranty:UK Mainland: 1 Year On-Site
Elsewhere: 1 Year Return and Collect

Prices (excluding VAT)

KV40 Metal Cutting Vertical Bandsaw + Keyswitch + Emergency Footstop
Height Adjustable Roller Stand. (1000 x 400 x 650-950mm)
Spare Blades
(one blade included with machine)
6-10 Vari Tooth Spare Blade
Order Code: MT-BM-BL3
10-14 Vari Tooth Spare Blade
Order Code: MT-BM-BL5

CAD Drawing (with Safe Working Area)

Available on request in DXF, DWG & DTD (2D Design) formats.
KV40 Metal Cutting Vertical Bandsaw CAD Drawing
